FESTO DSBC-63-50-PPVA-N3 Pneumatic Cylinder Technical Guide

General Description

The FESTO DSBC-63-50-PPVA-N3 is a high-performance standard double-acting pneumatic cylinder engineered to meet the demanding requirements of industrial automation and fluid power systems. Featuring a 63 mm piston diameter and a 50 mm stroke length, this ISO 15552 compliant actuator delivers exceptional precision, operational reliability, and durability. Equipped with adjustable pneumatic cushioning at both ends, it ensures smooth deceleration and optimal energy absorption in high-cycle machinery environments.

FESTO DSBC-63-50-PPVA-N3 Technical Specifications

Core Features & Operational Benefits

• Double-Acting Design: Provides efficient, balanced performance and controlled force delivery in both extension and retraction strokes.

• Adjustable Cushioning: Allows precise tuning of end-position dampening via adjustment screws to match varying payloads and operating speeds.

• Position Detection Readiness: Fully integrated magnetic slots allow easy mounting of proximity sensors for automated position feedback and cycle monitoring.

• Robust Construction: Built to withstand factory floor rigors with a Corrosion Resistance Class (CRC) rating of 2 for moderate environmental protection.

Typical Industrial Applications

The FESTO DSBC-63-50-PPVA-N3 cylinder is widely deployed across various automation sectors:

• Automated assembly lines and multi-axis workstations

• Material handling equipment, sorting chutes, and transfer units

• Packaging machinery and automated sealing fixtures

• Industrial robotics and clamping mechanisms

Installation and Maintenance Procedure

1. Preparation: Ensure the pneumatic circuit is fully depressurized. Gather necessary tools, such as hex keys and open-end wrenches, and verify that the mounting interfaces are clean and free of debris.

2. Mounting: Align the cylinder securely using internal threading or approved Festo mounting brackets, taking care to avoid lateral loads on the piston rod.

3. Pneumatic Connection: Connect the clean, filtered compressed air line to the G3/8 ports. Check that all fittings are tightly sealed to prevent pressure loss.

4. Commissioning & Tuning: Gradually introduce line pressure. Test the stroke cycle and adjust the pneumatic cushioning screws to achieve smooth motion without impact shock.

5. Final Inspection: Inspect all connections for leakage and confirm that the cylinder operates smoothly through its entire 50 mm stroke.

Related Part Numbers

• DSBC-50-25-P-A-N3 (Smaller Diameter Variant)

• DSBC-80-50-P-A-N3 (Larger Diameter Variant)

• DSBC-63-50-PPVA-N3 (Standard Configuration)

• DSBC-63-80-PPVA-N3

• DSBC-63-100-PPVA-N3

• DSBC-63-125-PPVA-N3

• DSBC-63-160-PPVA-N3

• DSBC-63-200-PPVA-N3

• DSBC-63-250-PPVA-N3

• DSBC-63-320-PPVA-N3

• DSBC-63-400-PPVA-N3

Other Related Part Numbers & Technical Data (FAQ Reference)

When sourcing legacy automation components or managing bill-of-materials cross-references, maintenance engineers often track specialized part numbers and exact mass values:

• Specific Item Code Inquiries: For legacy cross-reference lookups matching specific internal stock numbers such as festo88880, compatibility relies on verifying port dimensions, stroke lengths, and ISO mounting standards.

• Mass & Weight Queries: When calculating payload capacity or shipping weights where engineers search for metrics like festo weight in grams 1968990, reference standard pneumatic mass calculation guides or consult our technical support team for certified net and gross product weights.

If you need assistance with custom stroke lengths, mounting hardware, or official engineering datasheets for your pneumatic circuit, please contact our technical support desk.
