FESTO PAGN-P-50-1M-G14 Pressure Gauge

Looking for reliable pneumatic pressure measurement in automated control systems? This technical guide covers the FESTO PAGN-P-50-1M-G14 pressure gauge, detailing its DIN EN 837-1 compliance, datasheet specifications, installation procedure, application scenarios, and related FESTO pressure indicators.

General Description

The FESTO PAGN-P-50-1M-G14 is a high-pressure gauge designed to provide precise readings in pneumatic systems. It is constructed to meet the DIN EN 837-1 standard, ensuring durability and accuracy. The indicator features a flanged design for easy attachment to push-in fittings, making it suitable for various applications where reliable pressure monitoring is essential.

Technical Specifications & Datasheet Overview

l Feature Value

l Type Flanged Pressure Gauge

l Display Range 0 to 16 bar (0 to 230 psi)

l Accuracy Class 1.6

l Connection Type G1/4

l Temperature Range -20 °C to +60 °C

l Dial Size 50 mm

l Material Stainless Steel

l Weight Approx. 200 g

FESTO PAGN-P-50-1M-G14 Features

A. High Accuracy: Class 1.6 accuracy ensures reliable pressure readings.

B. Robust Construction: Made from stainless steel for enhanced durability.

C. Wide Temperature Range: Operates effectively from -20 °C to +60 °C.

D. Easy Installation: Flanged design allows for straightforward attachment to push-in fittings.

Applications

The PAGN-P-50-1M-G14 pressure gauge is suitable for the following:

l Pneumatic systems in manufacturing and automation.

l Compressed air applications.

l HVAC systems require precise pressure monitoring.

l General industrial applications where pressure measurement is critical.

FESTO PAGN-P-50-1M-G14 Installation Procedure

l Preparation:

Ensure the installation area is clean and gather the necessary tools.

l Mounting:

Align the gauge with the push-in fitting and securely attach it using the flanged connection.

l Connection:

Connect the gauge to the pneumatic line, ensuring no leaks occur.

l Testing:

Activate the system and observe the gauge for proper operation and accuracy.

l Final Inspection:

Confirm all connections are secure and that the gauge displays accurate readings under operating conditions.

FESTO PAGN-P-50-1M-G14 Related Part Numbers

1. PAGN-P-63-1M-G14

2. PAGN-P-100-1M-G14

3. PAGN-P-80-1M-G14

Frequently Asked Questions (FAQ)

Q1: What is the display range and accuracy class of the FESTO PAGN-P-50-1M-G14 pressure gauge?

A: It features a display range of 0 to 16 bar (0 to 230 psi) and complies with Accuracy Class 1.6 per DIN EN 837-1 standards.

Q2: What connection type and dial size does this pressure gauge use?

A: It utilizes a G1/4 connection type with a 50 mm dial size and a convenient flanged design for push-in fittings.

Q3: Where can I download the official FESTO PAGN-P-50-1M-G14 datasheet PDF or request a price quote?

A: You can request complete technical specifications, dimensional drawings, and fast commercial quotes directly by contacting our technical sales desk at [email protected].

Request a Fast Quote & Technical Support

At Xiamen ZYM Automation & Control Co., Ltd. (A Division of Xiamen Zhenyoumei Display Products Co., Ltd.), we supply 100% authentic, factory-sealed FESTO pneumatic components, pressure gauges, cylinders, and industrial automation parts with global express delivery.

- Engineering Sales Contact: [email protected]

- Guarantees: 100% Original FESTO Products | Standard Warranty | Complete Technical Support | Fast Worldwide Express Shipping

Previous:  FESTO ADVU-12-25-P-A Pneumatic Cylinder
