900R12-0300 Honeywell Combustion 12-Slot Rack

The Honeywell 900R12-0300 12-Slot Rack works with HC900 and ControlEdge systems. It contains CPU, power, and I/O modules. It supports local and remote I/O. It provides reliable, safe, and efficient control for boilers, furnaces, kilns, and other industrial combustion processes.

1. Honeywell 900R12-0300 Descriptions:

The Honeywell 900R12-0300 Combustion 12-Slot Rack is an important part of the Honeywell ControlEdge™ HC900 system. It helps control and protect many kinds of combustion processes.

This rack has twelve slots where you can place a mix of CPU, power supply, and I/O cards. You can set it up in different ways to match the needs of your process. The design makes it simple to install, expand, or replace parts when needed.

You can use the 900R12-0300 in tough jobs like boilers, furnaces, kilns, or thermal oxidizers. It works well in these areas because it is strong, steady, and built for long life.

The rack also supports both local and remote I/O, so it connects easily to larger control systems. The HC900 controller family gives you accurate combustion control, strong safety features, and meets industry standards.

2.Specifications:

l Size and Weight

ü The rack is 137 mm high (about 5.4 inches).

ü The width measures 571.5 mm (about 22.5 inches).

ü The depth is 151.7 mm (about 6.0 inches).

ü It weighs about 4.1 kg (9 lbs).

l Working Conditions

ü You can run the rack in temperatures from –40 °C to +70 °C.

ü It can also handle tough storage and plant conditions.

l Slots and Use

ü The rack has 12 open slots.

ü You can add CPU, power, or I/O cards in these slots.

ü It works with the HC900 / ControlEdge 900 platform.

ü This makes it easy to set up different control systems.

l Mounting and Build

ü You can mount the rack on a surface with four screws.

ü The design follows IEC and UL safety standards.

ü They build it to last in industrial areas.

3.Similar Racks and the features:

A. 900R04-0300 4 I/O Slot Rack

The rack is small and space-saving. It holds up to four I/O cards, making it a good fit for smaller systems. You can mix CPU, power, and I/O cards in any slot as needed. Its tough build and easy mounting make it dependable in industrial use.

B. 900R08-0300 8 I/O Slot Rack

The Honeywell Slot Rack gives you more room for control. It supports up to eight I/O cards, making it useful for medium-sized systems. You can add CPU, power, and I/O cards in any slot. Its strong design and easy mounting keep it reliable in tough industrial jobs.

C. 900R08R-0300 8 slot rack -red. power

The 8-Slot Rack comes with a redundant power supply for extra safety. It supports up to eight I/O cards, offers strong reliability, and fits medium-sized control systems.

D. 900R12R-0300 12 Slot Rack - Red. Power

The 12-Slot Rack features redundant power for high reliability. It supports up to twelve I/O cards, giving flexibility for large systems. Its rugged build, easy mounting, and strong compatibility with HC900 controllers make it ideal for demanding industrial applications.

E. 900R01-0300 1 I/O slot Rack Non-Redundant Power Assembly

The Honeywell 1-Slot Rack has one I/O slot and non-redundant power. This makes it great for small or standalone control systems. Its compact design saves space, and you can easily install a CPU, power, or I/O module. The builders construct the rack strong for reliable, long-term use in industrial environments.

F. 900PSM-0200 Redundant Power Status Module

The Power Status Module monitors the health of redundant power supplies in HC900 systems. It provides clear status signals, helps prevent downtime, and ensures continuous operation. Easy to install and reliable, it enhances system safety and efficiency in industrial control applications.

4. Applications:

l The 12-Slot Rack controls industrial combustion and process systems. It works with HC900 and ControlEdge controllers to manage boilers, furnaces, kilns, and thermal oxidizers.

l The rack has twelve slots. You can install CPU, power, and I/O modules in any combination. This gives engineers the flexibility to build systems that fit their process needs.

l You can easily expand the system by adding or changing modules. This reduces downtime and lowers maintenance costs.

l The rack is strong and can handle tough industrial conditions like heat, vibration, and electrical noise. It also supports local and remote I/O, so it connects easily with larger control networks.

l Using the 900R12-0300 improves temperature and combustion control. It helps save fuel, reduce emissions, and keep equipment and workers safe.

5.Our commitment

We are a top supplier of spare parts in this industry. We offer a 1-year warranty on all digital output relay and IO modules, starting from the date of purchase. We guarantee the replacement or refund for all the parts because of the responsibility of mine.
