Siemens HMI 6AV2124-1JC01-0AX0

The Siemens HMI 6AV2124-1JC01-0AX0 is a KP900 Comfort Panel designed for industrial automation. It features a 9" widescreen TFT display with key operation and supports PROFINET and MPI/PROFIBUS DP interfaces. This device is configurable using WinCC Comfort V11 and operates on the Windows CE 6.0 platform.

6AV2124-1JC01-0AX0 Product Specifications and Parameters

l Display: 9" TFT widescreen display with LED backlighting, 800x480 resolution, and 16 million colors.

l Control Elements: 26 function keys with LEDs, numeric and alphanumeric keyboards.

l Supply Voltage: DC 24 V, range 19.2 V to 28.8 V.

l Power Consumption: Approximately 18 W.

l Interfaces: 1 industrial Ethernet interface, 1 RS 422/485 interface, 2 USB interfaces.

l Protocols: PROFINET, MPI/PROFIBUS DP, TCP/IP, DHCP, SNMP.

6AV2124-1JC01-0AX0 Application Fields

This HMI suits various industrial automation applications, including process control, manufacturing, and monitoring systems. It can be integrated with Siemens S7 series PLCs and other compatible devices.

6AV2124-1JC01-0AX0 Device Properties

l Mounting Options: Vertical installation in landscape format is possible, with a maximum tilt angle of 35°.

l Clock and Timekeeping: Real-time hardware clock with a backup duration of up to 6 weeks.

l Security Features: Supports multiple user groups and rights management.

6AV2124-1JC01-0AX0 Benefits

1. Offers a user-friendly interface with customizable screens.

2. Supports multiple communication protocols for seamless integration.

3. Durable construction with cast aluminum front.

Similar Models

l 6AV2124-0JC01-0AX0: Similar model with touch operation instead of key operation.

l 6AV2124-1GC01-0AX0: KP700 Comfort model with a 7" display.
