Siemens 545-1104 Analog Input Module

This comprehensive setup ensures high performance and reliability across demanding industrial applications, making Siemens 545-1104 a preferred choice for advanced automation needs.

Technical Specifications of Siemens 545-1104

² Model Number: 545-1104

² Series: Siemens 545 Controller

² Type: Analog Input Module

² Power Requirements: 24 VDC input

² Input Range: Supports a range of ±5V, 0–10V, or 0–20mA (depending on configuration)

² Resolution: 12-bit

² Isolation: Galvanic isolation for signal integrity and noise reduction

² Channels: 8 differential analog inputs

² Sampling Rate: Configurable per application requirements

Detailed Features of Siemens 545-1104

1. High-Precision Analog Inputs: Equipped with 12-bit resolution for accurate data processing, essential for critical industrial applications.

2. Configurable Input Range: Supports various voltage and current ranges, making it versatile for multiple sensor types and setups.

3. Galvanic Isolation: Ensures protection from electrical interference and maintains signal integrity by isolating each channel.

4. Modular Design Compatibility: Integrates seamlessly into Siemens 545 Controller systems, allowing for scalable automation solutions.

5. Industrial Durability: Built to withstand industrial conditions, including temperature variations and electrical noise.

6. Diagnostic LEDs: Provides immediate visual feedback for channel status, enabling quick troubleshooting.

7. Efficient Data Acquisition: Designed to handle high-frequency sampling, suitable for applications requiring fast data refresh rates.

Applications of Siemens 545-1104

ü Process Control Systems are ideal for monitoring analog sensor outputs, such as pressure, temperature, and flow sensors, in automated control systems.

ü Industrial Automation: Commonly used in manufacturing environments where precise analog input measurements are critical.

ü Energy Management Systems: Enables accurate data collection from various energy meters for analysis and control.

ü Water and Wastewater Treatment: Monitoring parameters like pH, turbidity, and chemical concentrations in treatment plants.

ü Building Automation: Suitable for HVAC control systems and environmental monitoring in commercial and industrial buildings.

Related Part Numbers of Siemens 545-1104

l Siemens 545-1105: Analog Output Module compatible with the Siemens 545 Controller series.

l Siemens 545-1202: Digital Input Module, designed for high-speed data acquisition within the same series.

l Siemens 545-1304: Digital Output Module, providing output control compatible with the 545 Controller series.

l Siemens 545-1501: CPU module for 545 Controller series, supporting advanced processing and automation logic.
