Siemens 6AV6 647-0AE11-3AX0 - Simatic Mobile Panel 177 DP

Technical Specifications of Siemens 6AV6 647-0AE11-3AX0

ü Display: 5.7-inch, FSTN LCD, monochrome, 320 x 240-pixel resolution

ü Input Method: Membrane keyboard with function keys, alphanumeric input, and a touchscreen option

ü Communication: PROFIBUS-DP interface, 12 Mbps maximum baud rate

ü Processor: ARM-compatible processor designed for real-time response in industrial automation

ü Memory: 512 KB application memory, 512 KB project memory

ü Power Supply: 24 V DC (± 20%), max. 15 W power consumption

ü Environmental Ratings: IP65-rated front panel, suitable for demanding industrial environments

ü Operating Temperature: 0°C to 50°C (32°F to 122°F)

ü Dimensions (W x H x D): 243 mm x 159 mm x 54 mm

ü Weight: Approximately 1.2 kg

Detailed Features of Siemens 6AV6 647-0AE11-3AX0

1) High-Contrast Display: The Mobile Panel 177 DP's FSTN LCD ensures clear, readable monochrome visualization even in diverse lighting conditions, ideal for operator feedback in real-time.

2) Customizable Function Keys: Equipped with a membrane keyboard featuring fully programmable function keys, allowing users to tailor input commands based on operational needs.

3) Durability and Protection: The front panel's IP65 protection enables safe usage in challenging environments, safeguarding against dust and water splashes.

4) Real-Time PROFIBUS Communication: The Advanced PROFIBUS-DP interface seamlessly integrates with other Siemens automation equipment, enabling rapid data exchange and process monitoring.

5) Safety Integration: Designed with emergency stop and protective shutdown functions, ideal for high-safety applications.

6) User-Friendly Interface: The combination of function keys and touchscreen capability offers flexible control options, making navigating through complex automation processes easy.

Applications of Siemens 6AV6 647-0AE11-3AX0 :

² Manufacturing: Ideal for use on production floors for machine control, monitoring, and diagnostics.

² Process Automation: Suitable for industries requiring constant real-time monitoring and adjustments, such as food processing, pharmaceuticals, and chemical manufacturing.

² Material Handling: Designed for managing conveyors, automated guided vehicles (AGVs), and warehouse robotic controls.

² Heavy Industries: Effective in industries with rigorous environments, including automotive manufacturing and metal processing facilities.

Related Part Numbers of Siemens 6AV6 647-0AE11-3AX0 :

l 6AV6 647-0AA00-0AX0 - Siemens Mobile Panel 170, with a similar function but fewer programmable keys.

l 6AV6 648-0BC11-3AX0 - Mobile Panel 277 DP, with an enhanced color display and additional communication interfaces.

l 6AV6 643-0CD01-1AX1 - Simatic OP 177B, a stationary operator panel with similar functionalities for fixed installations.

l 6AV2 124-0GC01-0AX0 - Protective enclosure for mobile panels, suitable for enhancing ruggedness in harsh environments.
