Siemens 6DD1682-0CH0 Digital Input Module

The Siemens 6DD1682-0CH0 Digital Input Module is a robust and versatile component for various industrial applications. Its high input count, configurability, and reliable design make it suitable for factory automation, process control, and building automation systems. Its compatibility with the Siemens S5 series ensures seamless integration into existing setups, enhancing overall operational efficiency.

1) General Information of Siemens 6DD1682-0CH0

l Product Type: Digital Input Module

l Manufacturer: Siemens

l Part Number: 6DD1682-0CH0

l Series: S5

2) Electrical Specifications of Siemens 6DD1682-0CH0:

l Input Voltage: 24 V DC

l Input Current: ≤ 0.2 mA per input

l Number of Inputs: 16

l Signal Type: Digital

l Input Filter Time: Configurable, typically 1 ms

l Isolation: Galvanic isolation between inputs and bus

3) Physical Specifications of Siemens 6DD1682-0CH0 :

l Dimensions: 100 mm (H) x 150 mm (W) x 40 mm (D)

l Weight: Approximately 0.5 kg

l Mounting Type: DIN rail mountable

l Environmental Conditions:

² Operating Temperature: 0 to 60 °C

² Storage Temperature: -25 to 70 °C

l Humidity: 5 to 95% (non-condensing)

l Communication:

l Interface: Compatible with Siemens S5 systems

l Data Transmission Rate: Dependent on the S5 processor configuration

4) Detailed Features of Siemens 6DD1682-0CH0:

A. High Input Count:

It supports up to 16 digital input signals, providing flexibility for various applications.

B. Configurable Input Filters:

Input filter settings can be adjusted to prevent erroneous readings from noisy environments, allowing reliable operation in industrial settings.

C. Robust Design:

The module is designed for reliability and longevity in demanding environments and is built to withstand industrial conditions.

D. Galvanic Isolation:

E. It protects against voltage spikes and noise, ensuring stable performance and extending the module's life.

User-Friendly Installation:

Easily mounts on standard DIN rails, simplifying integration into existing systems.

5) Applications of Siemens 6DD1682-0CH0:

A. Factory Automation:

They are used in control systems to monitor the on/off states of various devices, such as sensors, switches, and safety equipment.

B. Process Control:

It is ideal for industries requiring precise monitoring of digital signals, including chemical processing and manufacturing.

C. Building Automation:

They are integrated into systems for managing HVAC, lighting, and security systems, allowing centralized control and monitoring.

6) Related Part Numbers of Siemens 6DD1682-0CH0 :

l Siemens 6DD1680-0CH0: Similar digital input module with different specifications.

l Siemens 6DD1681-0CH0: An alternative module in the same series offering different input configurations.

l Siemens 6ES5 975-0AA01: Related spare parts and accessories for S5 systems.
