Siemens 6SE7090-0XX84-0AH2 T300 series board

General Description

The Siemens 6SE7090-0XX84-0AH2 is a technology board designed for the SIMOVERT MASTERDRIVES T300 series. This module is critical in various industrial automation applications, providing advanced control and monitoring capabilities for drive systems.

Technical Specifications

l Product Type: Technology Board

l Dimensions: 300 x 400 x 300 mm

l Weight: 2 kg

l Processor: 80C186

l RAM: 128 KByte

l Binary Inputs: 16

l Binary Outputs: 8

l Analog Inputs: 7

l Analog Outputs: 4

Detailed Features

A. Robust Design: Engineered for durability in harsh industrial environments.

B. High Performance: Equipped with a powerful processor and sufficient RAM for efficient operation.

C. Versatile Connectivity: Multiple binary and analog inputs/outputs facilitate integration with various systems.

D. User-Friendly Interface: Simplifies configuration and monitoring processes.

The Siemens 6SE7090-0XX84-0AH2 is utilized in:

1. Industrial automation systems

2. Drive control applications

3. Robotics and motion control systems

4. Process control environments

Installation of the Siemens 6SE7090-0XX84-0AH2 involves:

l Ensuring the power supply is disconnected.

l Mounting the module securely within the designated enclosure.

l Connecting the necessary input/output wiring according to the system specifications.

l Power up the system and perform initial configuration via the user interface.

Related Part Numbers

l Siemens SIMOVERT MASTERDRIVES T300 series components.

l Siemens 6SE7090-0XX84-0AH2

l Siemens 6SE7090-0XX84-0AH0

l Siemens 6SE7090-0XX85-0AH2

l Siemens 6SE7090-0XX84-0AH1

For the previous part, please refer to the link: 6SE7031-2EP85-0AA0
