Siemens A5E01708486 Robicon Switch Board

The Siemens A5E01708486 is a robust Robicon switchboard for efficient signal conditioning in various industrial applications. This electronic module is crucial for converter PCA, ensuring reliable performance and seamless integration into existing systems.

Technical Specifications

l Manufacturer: Siemens

l Part Number: A5E01708486

l Dimensions: 6.5 cm x 14.7 cm x 3.3 cm

l Weight: 0.5 kg

l Transmission Rate: 10 Mbit/s, 100 Mbit/s

l Electrical Connections:

n For network components: 5 (RJ45 with securing collar)

n For power supply: 1 (2-pole terminal block)

l Supply Voltage: External DC voltage from 18 V to 32 V

l Maximum Current Consumption: 0.08 A

l Power Loss: 2 W at DC/24 V

Detailed Features

A. Integrated Communication Interfaces: Supports multiple network components with secure RJ45 connections.

B. Fusing Protection: Equipped with a fuse at the power supply input for enhanced safety.

C. Compact Design: Lightweight and compact dimensions facilitate easy installation in various setups.

D. Versatile Voltage Range: Operates efficiently within a wide voltage range, making it adaptable to different environments.

E. The Siemens A5E01708486 is widely used in:

F. Industrial Automation: Enhancing the performance of control systems and machinery.

G. Signal Conditioning: Ensuring accurate data transmission and processing in various electronic systems.

H. Power Management Systems: Integrating seamlessly into power distribution networks for improved efficiency.

I. Process Control Systems: Supporting real-time monitoring and control of industrial processes.

To install the Siemens A5E01708486:

1. Ensure power is turned off before installation.

2. Connect the electrical connections per the specifications, ensuring secure RJ45 connections for network components.

3. Attach the power supply to the designated terminal block.

4. Verify all connections are secure and power on the system to test functionality.

Related Part Numbers

l A5E01688153 (PT100 Temperature Sensor)

l A5E01688211 (Heating Cartridge for Injector)

l A5E02022461 (Capacitive Level Switch)

For the previous part, please refer to the link: Siemens A5E01649374
