Siemens DC1136-AA Power Supply Module

General Description of Siemens DC1136-AA:

The Siemens DC1136-AA Power Supply Module is a reliable and efficient solution that provides 24V DC output for industrial control systems. With a robust design, efficient performance, and advanced protection features, this module ensures stable power delivery to critical automation equipment, making it a trusted choice for industrial environments.

Technical Specifications:

l Model: DC1136-AA

l Input Voltage Range: 85–264V AC

l Output Voltage: 24V DC

l Output Current: 5A

l Efficiency: ≥ 90%

l Operating Temperature Range: -20°C to +70°C

l Mounting: DIN rail or panel

l Protection: Overload, short circuit, and overvoltage protection

l Certifications: CE, UL, and RoHS compliant

l Dimensions (L x W x H): 120 x 60 x 120 mm

Detailed Features:

l High Efficiency: With an efficiency rating of up to 90%, the DC1136-AA minimizes energy loss, reducing operating costs and heat generation.

l Comprehensive Protection: Integrated protection features, including overload, short circuit, and overvoltage, safeguard the power supply module and connected devices.

l Compact and Robust: The small form factor and durable construction ensure easy integration into control panels, even in space-constrained environments.

l LED Indicators: The unit has LED status indicators that allow operators to check the power supply’s operational health quickly.

l Flexible Mounting Options: It is suitable for both DIN rail and direct panel installation, providing flexibility to meet different system configurations.

Applications of Siemens DC1136-AA :

A. Industrial Automation Systems: Ideal for powering PLCs, HMIs, and control systems.

B. Machine Control and Robotics: Provides stable DC power for machine tools and robotic applications.

C. Renewable Energy Systems: Power equipment in solar and wind power systems ensures reliable energy conversion.

D. Energy Management: Used in energy monitoring and management systems for continuous operation.

Installation:

1. Ensure the power is off before installation.

2. Mount the module onto a DIN rail or secure it to a panel.

3. Connect the input terminals to the power source and output terminals to the load according to the wiring diagram.

4. After all connections are made, turn the power on.

5. Check the LED indicators to ensure proper operation.

Related Part Numbers of Siemens DC1136-AA :

l DC1136-AB – Alternative power configuration model

l DC1136-AC – Version with additional features

l DC1136-AD – Compact model for limited installation space

For the previous part, please refer to the link: Siemens DC1154-AA
