Technical Specifications of SIEMENS 6ES7960-1AA04-5AA0

l Part Number: SIEMENS 6ES7960-1AA04-5AA0

l Product Type: Communication Processor

l Compatibility: Siemens S7-400 PLC Series

l Interface: Ethernet / Industrial Ethernet (Profinet)

l Transmission Rate: Up to 100 Mbps

l Operating Temperature: 0°C to 60°C (32°F to 140°F)

l Storage Temperature: -40°C to 70°C (-40°F to 158°F)

l Mounting: DIN Rail mountable

l Power Supply: 24 V DC (Nominal)

l Protection Class: IP20

l Dimensions: 150 mm x 125 mm x 45 mm (HxWxD)

l Weight: 0.3 kg (approx.)

l Status Indicators: LEDs for status, diagnostics, and network communication

l Programming/Configuration: Can be programmed using Siemens TIA Portal or STEP 7

l Certifications: CE, UL, RoHS

Detailed Features of SIEMENS 6ES7960-1AA04-5AA0

1. High-Performance Communication: This feature facilitates high-speed, reliable communication between Siemens PLCs and other automation devices via Ethernet or Profinet.

2. Efficient Data Exchange: Supports real-time data exchange and diagnostic data transmission, ensuring smooth and uninterrupted operations.

3. Scalable Network Architecture: It seamlessly integrates into small and large automation networks with high scalability, offering a versatile solution for different industrial environments.

4. Flexible Protocol Support: Provides wide-ranging protocol support, including TCP/IP, Profinet, and more, making it adaptable to diverse industrial control systems.

5. Compact and Robust Design: It is designed for easy integration into control cabinets, with minimal space requirements and excellent environmental resistance for industrial settings.

6. Diagnostics and Monitoring: Built-in diagnostic features allow for continuous network and system status monitoring, minimizing downtime and improving reliability.

Applications of SIEMENS 6ES7960-1AA04-5AA0

l Industrial Automation: Ideal for high-performance communication in automation systems, especially in industries like manufacturing, oil & gas, automotive, and food processing.

l PLC Networking: This technology is perfect for connecting Siemens PLC systems in large and complex control networks, enabling smooth data transfer and centralized control.

l Smart Factory Systems: Suitable for use in Industry 4.0 environments where seamless communication between different devices is crucial.

l Process Control: Used in process automation systems that require precise, real-time data exchange and diagnostics for optimal performance.

Related Part Numbers of SIEMENS 6ES7960-1AA04-5AA0

l 6ES7960-1AA04-5AA0 – Siemens Communication Processor (Primary)

l 6ES7960-0AA04-0AA0 – Similar Ethernet-based Communication Processor

l 6ES7960-3BA10-1AA0 – Ethernet Communication Processor with higher I/O capacity

l 6ES7960-1CA01-0AA0 – Communication processor for industrial applications
