Woodward 8200-224 Servo Position Controller | Technical Specs & Buying Guide

1. Technical Specifications of Woodward 8200-224

2. Key Features & Industrial Advantages

• High-Precision Actuator Control: Delivers closed-loop positioning accuracy with minimal hysteresis, stabilizing high-load industrial systems.

• Harsh Environment Durability: Housed in a NEMA 4X-rated enclosure, protecting internal circuitry from severe moisture, dust, and corrosive elements.

• Integrated Safety & Diagnostics: Built-in real-time diagnostics streamline troubleshooting, while engineered fail-safe modes protect equipment during power interruptions.

• Flexible System Integration: Supports diverse feedback loops (analog/digital) and standard 4-20 mA or PWM outputs for broad compatibility with legacy and modern systems.

3. Industrial Applications

The Woodward 8200-224 controller is widely deployed across mission-critical sectors:

• Power Generation: Manages turbine governors and fuel-metering valves for stable grid synchronization.

• Oil & Gas: Controls critical valve positioning in remote pipelines, refineries, and drilling rigs.

• Industrial Automation: Drives heavy-duty actuators in high-precision processing and manufacturing lines.

• Marine Systems: Regulates throttle and steering actuator positions under dynamic marine conditions.

• Renewable Energy: Interfaces with wind turbine blade pitch systems for optimized power capture.

4. Step-by-Step Installation & Wiring Guidelines

Safety Notice: Always isolate and turn off system power before initiating physical installation or wiring to prevent electrical shock or hardware damage.

1. Mounting Location: Secure the controller on a stable, vibration-dampened surface with adequate ambient ventilation to prevent heat buildup.

2. Power Supply Wiring: Connect the 18–32 VDC input power to the designated terminals, verifying correct polarity.

3. Signal Shielding: Use shielded cables for all position feedback and I/O connections to minimize electromagnetic interference (EMI) in industrial settings.

4. Actuator & Feedback Setup: Link the controller to the target actuator and position feedback sensor, ensuring mechanical alignment.

5. Parameter Configuration: Power on the unit and configure the desired control loops, travel limits, and feedback profiles via the interface.

6. Functional Testing & Calibration: Run initial stroke tests, verify positioning accuracy, and fine-tune output parameters for optimal dynamic response.

5. Related Woodward Series & Alternatives

To support complete plant maintenance and spare parts management, we also supply associated models:

• Woodward 8200-225

• Woodward 8200-226

• Woodward 8200-227

• Woodward 8200-228

6. Frequently Asked Questions (FAQ) for B2B Buyers

• Q: Are these Woodward 8200-224 controllers brand new and original?

  A: Yes, we specialize in supplying 100% brand-new, factory-original industrial automation and turbine control components.

• Q: What is the typical shipping lead time for this part?

  A: For in-stock items, orders are normally processed and dispatched within 24 to 48 hours utilizing secure international express carriers.

• Q: How can I place an order or get a formal commercial invoice?

  A: Click the "Get a Quote" button on our site or email your exact part number, quantity, and destination to our sales team for a prompt, competitive quotation.
