Johnson Controls E98-PLUS Control System

General Description

The Johnson Controls E98-PLUS is an advanced control system designed for HVAC applications. It provides enhanced management and monitoring capabilities. This versatile system is engineered to optimize building performance while ensuring energy efficiency and user-friendly operation.

Technical Specifications of Johnson Controls E98-PLUS

l Model Number: E98-PLUS

l Input Voltage: 24 VAC

l Power Consumption: 10 VA (typical)

l Communication Protocols: BACnet, LonTalk, Modbus

l Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)

l Dimensions: 8.5 x 6 x 2 inches

l Weight: 1.5 lbs

l Display Type: LCD with backlight

Detailed Features of Johnson Controls E98-PLUS

l Multi-Protocol Support: Compatible with various communication protocols, allowing integration with existing systems.

l User-Friendly Interface: Features an intuitive LCD for easy navigation and monitoring of system parameters.

l Flexible Configuration Options: Customizable settings to meet specific application requirements.

l Integrated Scheduling Functions: Allows users to set schedules for heating and cooling, enhancing energy savings.

l Durable Construction: Designed to withstand harsh environmental conditions, ensuring long-term reliability.

Applications

The Johnson Controls E98-PLUS is suitable for a variety of applications, including:

A. Commercial Buildings: Manages HVAC systems in offices, retail spaces, and public facilities to maintain comfortable environments.

B. Industrial Facilities: Optimizes heating and cooling processes in manufacturing plants and warehouses, promoting efficiency.

C. Educational Institutions: Provides effective climate control in schools and universities, enhancing learning environments.

D. Healthcare Facilities: This position ensures reliable HVAC operation in hospitals and clinics, which is critical for patient comfort and safety.

Installation

To install the Johnson Controls E98-PLUS:

l Preparation: Ensure all power sources are disconnected before installation begins.

l Mounting Location: Select a suitable location on a wall or panel that allows easy access to the display.

l Wiring Connections: Connect the input power and communication lines according to the wiring diagram.

l Secure the Unit: Attach the control system to the mounting surface using appropriate screws or brackets provided.

l Power Up and Test: Reconnect power, check the display functionality and perform tests to ensure proper operation of HVAC controls.

Related Part Numbers

l E98-MOD

l E98-SENSOR

l E98-CONTROLLER
