Johnson Controls JSM-M301MJC building management system

General Description

The JSM-M301MJC is engineered to support a wide range of applications in commercial buildings, focusing on energy management, environmental control, and system integration. It helps facility managers maintain optimal conditions while ensuring compliance with energy regulations.

Technical Specifications

l Model: JSM-M301MJC

l Power Supply: 24V AC/DC

l Communication Protocols: BACnet/IP, Modbus TCP/IP

l Dimensions: 10 x 8 x 2 inches

l Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)

l Weight: 1.5 lbs

Detailed Features of JSM-M301MJC

1. Multi-Protocol Support: The device supports BACnet and Modbus protocols, allowing easy integration with existing systems.

2. Scalability: Designed to accommodate growing building management needs by supporting additional sensors and devices.

3. Data Logging Capabilities: Tracks historical data for analysis and reporting, aiding decision-making processes.

4. User Access Levels: Provides customizable user permissions for enhanced security and management control.

Applications of JSM-M301MJC

The JSM-M301MJC is suitable for various applications, including:

l Commercial Buildings: Enhances HVAC performance and occupant comfort in offices and retail spaces.

l Industrial Facilities: Monitors environmental conditions critical for manufacturing processes.

l Educational Institutions: Manages climate control in classrooms and common areas.

l Healthcare Facilities: Ensures optimal conditions in patient care environments.

Installation of JSM-M301MJC

l Preparation :

Ensure all necessary tools and equipment are available, including mounting hardware and wiring.

Review the installation manual provided by Johnson Controls.

l Mounting:

Securely mount the JSM-M301MJC on a wall or panel using appropriate hardware.

Ensure it is located in a position that allows for optimal sensor placement.

l Wiring:

Connect the power supply to the designated terminals on the device.

Wire communication lines according to the selected protocol (BACnet or Modbus).

l Configuration:

Use the onboard interface or software tools to configure settings based on your specific application needs.

Test connectivity with other devices in your network.

l Final Checks:

Verify all connections and perform a system check to ensure proper functionality before full deployment.

Related Part Numbers

l JSM-M201MJC

l JSM-M401MJC

l JSM-M501MJC

Previous: Johnson Controls JSM-M300CJC
