Honeywell TC810A1056 Control Module

1.General Description

The Honeywell TC810A1056 Control Module, also called the HONEYWELL TC810A-1056, is important for Honeywell fire alarm systems. This HONEYWELL INTELLIGENT CONTROL MODULE provides intelligent control for auxiliary devices and ensures that critical functions activate automatically during fire or alarm conditions.

The design of the HONEYWELL TC810A1056 Control Module Fire Alarm allows for easy integration into new and existing systems. It improves system performance by using built-in type identification. This feature automatically recognizes the device as a control module when it connects to compatible Honeywell fire alarm panels. Compact, reliable, and efficient, it is ideal for use in commercial, industrial, healthcare, and educational facilities where dependable fire safety control is essential.

2.Technical Specifications of Honeywell TC810A1056

l Model: Honeywell TC810A1056

l Type: Intelligent Control Module

l Output Type: Dry-contact output

l Current Consumption: Low standby current

l Mounting: Fits standard 4-inch junction box

l Addressing: Rotary address switches

3.Detailed Features

l Built-in Type Identification: Automatically identifies the HONEYWELL TC810A1056 as a control module, simplifying installation and configuration within Honeywell’s intelligent fire alarm network.

l Dry-Contact Output: Provides reliable activation of auxiliary devices such as fans, smoke dampers, and relays during alarm events.

l Analog Communication: Ensures seamless communication with Honeywell fire alarm control panels for consistent performance and system integration.

l Panel-Controlled Status LED: Offers visual indication of the device’s operational state for easy monitoring and diagnostics.

l User-Friendly Design: Rotary address switches and a modular construction allow quick setup, addressing, and maintenance.

4.Applications

The HONEYWELL TC810A1056 Intelligent Control Module is designed for versatility and is suitable for a wide range of applications:

A. Commercial Buildings: Enables control of HVAC systems to maintain air quality and smoke control during fire events.

B. Industrial Facilities: Activates and monitors critical safety equipment, including fans and dampers, to contain fire and smoke spread.

C. Healthcare Institutions: Interfaces with emergency ventilation and isolation systems, ensuring safety for patients and staff.

D. Educational Institutions: Integrates with comprehensive building safety systems to provide fast and automated responses during alarms.

5.Installation of Honeywell TC810A1056

Installing the Honeywell TC810A1056 Control Module involves:

l Selecting a proper mounting location within a standard 4-inch junction box.

l Connecting the module to the fire alarm control panel using manufacturer-specified wiring protocols.

l Setting the module’s unique digital address via the rotary switches for system recognition.

l Performing system testing to confirm proper functionality and communication with the fire alarm panel.

Engineers designed the HONEYWELL TC810A1056 CONTROL MODULE FIRE ALARM for easy installation, intelligent identification, and dependable operation in a variety of environments.

6.Related Part Numbers

l Honeywell TC810A1001

l Honeywell TC810A1002

l Honeywell TC810A1003
