Omron CP1W-AD041 Compact PLC unit
Omron CP1W-AD041 Product Features:
- 16-point output.
- Reduced wiring: Transmits 16-point I/O information over two signal lines.
- B7A interface unit: Transmits 16-point input/output signals through a single cable pair.
- I/O unit: Eliminates the need for communication considerations, enabling simplified wiring within control cabinets and for remote switches, indicators, and other I/O devices.
Omron CP1W-AD041 Specifications:
- Standard type with built-in analog functionality.
- Power supply: DC24V.
- Input points: 12 points (including 2 analog inputs).
- Output points: 8 points (including 1 analog output).
- Output type: Transistor (sourcing).
- Program capacity: 8K steps.
- Data memory capacity: 8K words.
- Advanced control performance and functionality: Widely applicable.
- Built-in high-speed counter and pulse output functions: Suitable for serial connection ports.
- Expandable with extension units and option boards: Supports various device controls.
- Pulse output function: Available only in transistor output models.
- Positioning control: Achieved using 100kHz, 2-axis pulse output.
- Modbus-RTU simple master function.
- Built-in RS-485 for inverter speed control.
- Analog input/output functionality: High-resolution control at 1/12,000.
- Expandable I/O points: Up to 24 points using extension units.
Omron CP1W-AD041 Performance Overview:
- 10-point I/O model (Omron OC211).
- Connector (MIL).
- Required I/O connectors: 2.
- Input: DC24V, 6 points.
- Output: Transistor (sinking), 4 points.
- Timer function included.
- High functionality: Supports up to 192 I/O points in a compact design.
- Slim profile with functionality equivalent to CPM2A.
- Versatile machine control features are available in a small form factor.
- CPU models with relay output/transistor output, terminal block connector, and clock functionality (DC power supply) are available.
- Input points: 2 points. Converts analog input signals (voltage, current) into binary (BIN) data for internal processing.
Applications:
In industrial processes, many variables, such as temperature, pressure, flow, level, and speed, are analog. Analogue-to-digital (A/D) and Digital-to-analogue (D/A) conversions enable PLCs to handle analog signals. PLC manufacturers provide A/D and D/A conversion modules to facilitate analog control.
