Omron NX-DA2603 Analog Output Unit

General Description

The Omron NX-DA2603 is part of the NX series of modular I/O units designed to provide analog output capabilities in automation systems. This unit is ideal for controlling devices that require precise voltage signals, such as actuators, valves, and sensors. Its robust features and reliable performance make it suitable for various industrial applications.

Technical Specifications

l Specification Details

l Model Number NX-DA2603

l Type Analog Output Unit

l Number of Outputs 2

l Output Voltage Range -10 to +10 V

l Resolution 13 bits

l Conversion Time 0.5 ms/unit

l Signal Processing Free-running

l Connection Type Screwless push-in

l Degree of Protection IP20

l Dimensions (H x W x D) 104.5 mm x 12 mm x 80.1 mm

l Weight 70 g

l Operating Temperature 0 to 55 °C

Detailed Features

1. Detachable I/O Connector: Facilitates easy maintenance and replacement without disrupting wiring.

2. Overall Accuracy: ±0.3% at 25°C ensures reliable output performance across varying temperatures.

3. Allowable Load Resistance: Supports a minimum load resistance of 5 kΩ, making it suitable for various applications.

4. Synchronous or Free-run Refreshing: Allows selection between synchronous I/O refreshing or free-run refreshing based on application needs.

Omron NX-DA2603 Applications

The NX-DA2603 is ideal for numerous applications, including:

l Process Control Systems: Providing precise control signals to regulate processes in manufacturing environments.

l Robotics: Managing actuator movements with accurate voltage outputs for robotic arms and machinery.

l Industrial Automation: Integrating PLCs to control various devices such as valves and pumps.

l Testing Equipment: Used in laboratories and testing setups where accurate voltage outputs are required.

Omron NX-DA2603 Installation Process

1. Preparation:

Gather necessary tools (screwdriver, wire strippers) and components (NX-DA2603 module).

Ensure the power supply is turned off before installation.

2. Mounting the Unit:

Securely attach the NX-DA2603 module to a DIN rail or panel per specifications.

3. Wiring Connections:

Connect the output devices to the corresponding terminals using screwless push-in connectors.

Ensure proper grounding and wiring according to the specified configurations.

4. Power Connection:

Connect the power supply to the module within the specified voltage range.

5. Testing:

Power on the system and check LED indicators for operational status.

Test each output channel for proper functionality.

6. Precautions

Always disconnect the power before installation to prevent electrical shock.

Follow local electrical codes during wiring to ensure safety.

Ensure that the module operates within its specified temperature and humidity ranges.

Omron NX-DA2603 Related Part Numbers

Other models in the same series include:

l NX-DA2203 (Analog Output Unit, current output type)

l NX-DA3605 (Analog Output Unit with additional features)

l NX-DA2605 (Analog Output Unit with enhanced capabilities)
