Siemens HMI 6AV2124-1MC01-0AX0

The Siemens HMI 6AV2124-1MC01-0AX0 is a KP1200 Comfort Panel designed for high-performance industrial automation. It features a 12" widescreen TFT display with key operation and supports PROFINET and MPI/PROFIBUS DP interfaces. This device is configurable using WinCC Comfort V11 and operates on the Windows CE 6.0 platform.

Product Specifications and Parameters

l Display: 12" TFT widescreen display with LED backlighting, 1280x800 resolution, and 16 million colours.

l Control Elements: 34 function keys with LEDs, numeric and alphanumeric keyboards.

l Supply Voltage: DC 24 V, range 19.2 V to 28.8 V.

l Power Consumption: Approximately 20 W.

l Interfaces: 1 industrial Ethernet interface with two ports, 1 RS 422/485 interface, and 2 USB interfaces.

l Protocols: PROFINET, MPI/PROFIBUS DP, TCP/IP, DHCP, SNMP.

6AV2124-1MC01-0AX0 Application Fields

This HMI suits various industrial automation applications, including process control, manufacturing, and monitoring systems. It can be integrated with Siemens S7 series PLCs and other compatible devices.

Device Properties

A. Mounting Options: Vertical installation in landscape format is possible, with a maximum tilt angle of 35°.

B. Clock and Timekeeping: Real-time hardware clock with a backup duration of up to 6 weeks.

C. Security Features: Supports up to 50 user groups and 32 user rights.

6AV2124-1MC01-0AX0 Benefits

l Offers a user-friendly interface with customizable screens.

l Supports multiple communication protocols for seamless integration.

l Durable construction with cast aluminium front.

6AV2124-1MC01-0AX0 Similar Models

1. 6AV2124-1JC01-0AX0: Similar model with a 9" display instead of 12".

2. 6AV2124-1MA03-0AX0: Model with a different interface configuration.
