Siemens HMI 6AV2124-1QC02-0AX1: Key-Operated Comfort Panel

The Siemens HMI 6AV2124-1QC02-0AX1 is a key-operated Comfort Panel designed for industrial automation. It features a 15.4-inch widescreen TFT display with 16 million colors, making it suitable for complex process visualization. The device supports PROFINET and MPI/PROFIBUS DP interfaces, ensuring seamless integration with various industrial systems.

6AV2124-1QC02-0AX1 Product Specifications and Parameters

- Display: 15.4-inch widescreen TFT display with a resolution of 1280x800 pixels.

- Connectivity: PROFINET, MPI/PROFIBUS DP, industrial Ethernet (2 ports + independent port), RS 485, and USB 2.0 interfaces.

- Power Supply: 24V DC with a permissible range of 19.2V to 28.8V.

- Memory: 24 MB configuration memory, expandable via SD cards.

- Control Elements: 36 function keys with LEDs, numeric and alphanumeric keyboards.

6AV2124-1QC02-0AX1 Application Fields

This HMI suits various industrial applications, including manufacturing, process control, and automation systems. It is beneficial in environments requiring robust and reliable control interfaces.

6AV2124-1QC02-0AX1 Device Properties

- Mounting: It can be mounted in landscape format with a maximum inclination angle of 35°.

- Clock: Features a real-time hardware clock with a backup duration of up to six weeks.

- Acoustics: Equipped with a speaker for auditory feedback.

Benefits

The device offers a high-resolution display, versatile connectivity options, and robust control features, making it ideal for demanding industrial environments.

Similar Models

Similar models include the 6AV2124-1QC02-0AX2, which may offer additional features or slight variations in specifications.
