SIEMENS K3R072 Control Relay

General Description

The SIEMENS K3R072 is a high-performance control relay that provides reliable switching and control capabilities in various industrial automation applications. It features multiple contact configurations, enabling it to manage various loads and control tasks effectively. Its design is optimized for quick installation and integration into existing systems, making it suitable for new installations and upgrades.

Technical Specifications

l Type: Control Relay

l Rated Voltage: 24 V DC / 230 V AC

l Contact Configuration: 2 NO (Normally Open) + 2 NC (Normally Closed)

l Switching Capacity: Up to 16 A

l Protection Class: IP20

l Operating Temperature Range: -25°C to +60°C

l Dimensions: Compact form factor suitable for DIN rail mounting

Detailed Features

l LED Status Indicators: Each relay includes LED indicators for easy operational status monitoring.

l Quick-Mount Design: Facilitates fast installation on standard DIN rails, reducing setup time.

l Wide Voltage Range: Compatible with AC and DC voltages, enhancing application versatility.

l Safety Features: Built-in protection against overloads and short circuits to ensure safe operation.

The SIEMENS K3R072 is widely used in:

A. Industrial Automation: Controlling motors, pumps, and other machinery in manufacturing processes.

B. Building Management Systems: Managing lighting, HVAC, and security systems efficiently.

C. Process Control: Automating processes in chemical plants, water treatment facilities, and food processing industries.

D. Control Panels: These are key components in control panels for various electrical applications.

To install the SIEMENS K3R072 relay:

1. Ensure that the power is disconnected before installation.

2. Mount the relay securely on a DIN rail within the control cabinet.

3. Connect the input power supply according to the wiring diagram provided in the installation manual.

4. Wire the output contacts to the respective devices or loads as required.

5. Power up the system and verify functionality through LED indicators.

Related Part Numbers

l Siemens K3 Series Relays (e.g., K3R071)

l Siemens Control Modules (e.g., S7-1200 Controllers)

l SIEMENS K3R073

l SIEMENS K3R074

l SIEMENS 6ES7 345-1AH01-0AE0

l SIEMENS 6ES7 342-1AH01-0AA0
