WAGO 750-363 Module - Fieldbus Coupler Modbus TCP

General Description:

The WAGO 750-363 Module is a Fieldbus Coupler designed for Modbus TCP communication, connecting Ethernet to the modular WAGO I/O System. It is part of the fourth generation of WAGO's Fieldbus Couplers. It is designed to detect all connected I/O modules and create a local process image, facilitating efficient communication within industrial automation setups.

Technical Specifications of 750-363 module:

l The coupler is designed for Fieldbus communication in Modbus networks and supports various standard Ethernet protocols.

l It features two Ethernet interfaces that support auto-negotiation and Auto-MDI(X), which can be used for IP address assignment (DHCP, BootP, static).

l The coupler provides the system supply directly, while the field supply is provided via a separate supply module.

l The coupler also includes an integrated Webserver for user configuration and status display.

Detailed Features of 750-363 module:

1. The 750-363 Fieldbus Coupler connects Ethernet to the WAGO I/O System, creating a local process image by detecting all connected I/O modules.

2. The coupler has two Ethernet interfaces and an integrated switch, which allows for a line topology wiring, eliminating the need for additional network devices.

3. It supports auto-negotiation and Auto-MDI(X) on both interfaces and can be configured using a DIP switch for the last byte of the IP address.

4. The coupler is designed to work with a wide range of standard Ethernet protocols, enhancing its compatibility with various network systems.

Applications:

The WAGO 750-363 Fieldbus Coupler is ideal for machine and plant construction, process industry, and building technology applications. It provides reliable communication in MODBUS networks and supports various standard Ethernet protocols, making it a versatile solution for industrial automation.

Installation:

The WAGO 750-363 Fieldbus Coupler installation involves connecting it to the WAGO I/O System and configuring the IP address using the DIP switch or through the integrated Webserver. The coupler can be easily mounted on a DIN rail, and the system supply is provided directly by the coupler. In contrast, the field supply is provided via a separate supply module.

Related Part Numbers of 750-363 module :

l 750-363: Standard Fieldbus Coupler Modbus TCP

l 750-363/040-000: Extreme version of the Fieldbus Coupler Modbus TCP, designed for operation in extreme environments with extended temperature range, greater immunity to impulse voltages and electromagnetic interference, and higher vibration and shock resistance.

Previous: WAGO 750-362 PLC Module - Fieldbus Coupler Modbus TCP
