Endress+Hauser Promass F 80F50 80F50-AAASAAA9BAAD Flowmeter

1.General Description

The Endress+Hauser Promass F 80F50 is a precise Coriolis flowmeter. It measures liquids and gases accurately. Built for hazardous area and standard industrial applications, its robust construction ensures reliable operation in demanding environments.

The Promass F 80F50 can record multiple process variables at the same time. These include mass flow, volume flow, density, reference density, and temperature.

This ability lets us take many measurements of the same quantity. This reduces the need for many separate tools. It also ensures accurate monitoring in complex control systems.

Its intuitive push buttons and backlit display allow easy configuration and operation. The device works well with other Endress+Hauser devices. This list includes several devices.

- FML621 batch controller

- FMP53 guided radar level transmitter

- FMR52 radar device

- FMU40 ultrasonic sensor

- FTL31 point level switch Together, they create a complete system for monitoring flow, level, and processes.

2.Product Specifications and Parameters

l Measurement Accuracy and Errors:

l Mass flow (liquid): ±0.10% (standard), ±0.05% (option)

l Mass flow (gas): ±0.25%

l Volume flow (liquid): ±0.10%

l Density (liquid): ±0.0005 g/cm³

l Absolute errors, random error, and systematic error are minimized using advanced Coriolis technology, ensuring consistency in repeated measurements.

l Measuring Range: 0 to 2,200,000 kg/h (0 to 80,840 lb/min)

l Medium Temperature Range:

l Standard: –50 to +150 °C (–58 to +302 °F)

l Option: –50 to +240 °C (–58 to +464 °F)

l High temperature option: –50 to +350 °C (–58 to +662 °F)

l Process Pressure: PN 100, Class 600, 63K

l Nominal Diameter: DN 8 to 250 (³⁄₈ to 10")

l Materials and Process Connection:

l Measuring tube: 1.4539 (904L); 1.4404 (316/316L); Alloy C22, 2.4602 (UNS N06022)

l Connection: 1.4404 (316/316L); Alloy C22, 2.4602 (UNS N06022); 1.4301 (F304)

l Flexible process connection options including flanged, threaded, and hygienic designs.

3.Application Fields

The Promass F 80F50 is suitable for a wide range of industries and processes:

A. Chemical and petrochemical

 B. Food and beverage

 C. Pharmaceuticals

 D. Water and wastewater treatment

 E. Oil and gas

 F. Applications where pump dry run prevention, mechanically moved parts monitoring, or precise dosing is required.

4.Device Properties

a. Mass Flow Measurement: ±0.05% accuracy with PremiumCal option

b. Multi-variable Measurement: Records multiple variables simultaneously (mass flow, density, temperature, and more)

c. Medium Temperature Range: -196 to +350 °C (-320 to +662 °F)

d. Remote Transmitter: Available with up to 4 I/Os

e. Display and Control: Backlit display with push buttons, touch control, and WLAN access

f. Cable Length: Standard cable between sensor and transmitter

g. Compatibility: Works seamlessly with Endress+Hauser measuring and control devices (FML621, FMP53, FMR52, FMU40, FTL31)

5.Benefits

(1) High Process Safety: Resistant to harsh conditions and certified for hazardous area use.

(2) Simultaneous Recording of Multiple Measurements: Mass flow, density, temperature, and reference density from a single device.

(3) Error Minimization: Reduced measured error by addressing absolute errors, systematic error, and random error.

(4) Space-saving Installation: No inlet or outlet runs required.

(5) Full Access to Data: Ethernet, multiple I/Os, and integration with higher-level control systems.

(6) Reduced Complexity: Fewer instruments needed because of multi-variable capability.

(7) Integrated Verification: Heartbeat Technology ensures reliability during working days of continuous operation.

6.Similar Models

l Promass F 300: Compact version with similar multi-variable capabilities

l Promass F 500: Advanced model with higher accuracy and expanded options including digital communication interfaces
