Honeywell J-XAP-M-TC500H Commercial Thermostat

General Description

The Honeywell JXAP-M TC500H is a commercial thermostat. It has advanced features that enhance HVAC control for small and medium buildings. It features an intuitive user interface, advanced control algorithms, and robust connectivity options, making it ideal for efficient temperature management.

Technical Specifications

l Power Supply: 24VAC, 50/60Hz

l Power Consumption: Max 8.5VA @ 24VAC

l Display: 4" TFT with 480x480 resolution, dimmable backlight

l Operating Temperature Range: 32°F to 122°F (0°C to 50°C)

l Humidity Range: 10% to 90% RH (non-condensing)

l Protection Class: IP20

l Connectivity: BACnet IP, HMI configurations

Detailed Features

A. User Interface: Customizable with multiple user privilege levels and languages.

B. Control Algorithms: Supports auto changeover, demand limit controls, and pre-occupancy purge.

C. Sensor Inputs: Compatible with various CO2, occupancy, and temperature sensors.

D. Energy Efficiency: Features demand limit control to optimize energy usage.

E. Advanced Scheduling: Offers programmable schedules for heating and cooling modes.

The J-XAP-M-TC500H is suitable for:

l Commercial buildings (offices, retail spaces)

l Educational institutions

l Healthcare facilities

l Any environment requiring precise HVAC control

Installation

Installation should be performed by trained personnel following the manufacturer's guidelines. Key steps include:

1. Mount the thermostat in a suitable location away from direct sunlight or drafts.

2. Connecting the power supply and sensor inputs as per the wiring diagram.

3. Configuring settings via the HMI or BACnet interface.

Related Part Numbers

l TC500A-N

l TC500A-W

For more items you are interested in, please refer to the following:

Honeywell TC809B1008 Monitor Module

Honeywell TC811A1006 Fault Isolator Module

Honeywell J-SAP-M-TC500K Manual Alarm Button
